Market Report Description

The Global Hardware in the Loop Market size is expected to reach $1.5 billion by 2028, rising at a market growth of 10.4% CAGR during the forecast period.

The hardware-in-the-loop (HIL) simulation is a method used in testing and developing complex real-time embedded systems. These are also abbreviated as HWIL or HITL. By integrating the intricacy of the process-actuator system, or a plant, into a test platform, HIL simulation creates an efficient testing environment. The inclusion of a mathematical description of all connected dynamic systems in testing and development takes into account the complexity of the controlled plant. The term "plant simulation" refers to these mathematical depictions. This industrial simulation interacts with the embedded that is being tested.

Hardware in the Loop Market Size - Global Opportunities and Trends Analysis Report 2018-2028

Traditionally, testing of control systems has been done on actual machinery (i.e., plant) out in the field, on the entire system, or on a powered test bed in a lab. This method can be exceedingly costly, ineffective, and even dangerous while providing testing fidelity. HIL testing is a fantastic alternative to conventional testing techniques. When using a simulator with inputs and outputs (I/Os) capable of interacting with control systems and other equipment, a computer model exactly replicating the physical plant replaces it during HIL simulation. By precisely simulating the plant and its dynamics, as well as sensors and actuators, the HIL simulator can provide thorough closed-loop testing without the requirement for testing on actual systems.

In fields like aviation or automotive where operations are particularly complicated, HIL has been employed for years. HIL can supplement the testing of physical plants to offer a number of benefits. One such benefit is reduced testing costs. A significant investment in HIL can be justified by the high costs associated with testing complex machinery like airplane subsystems. By adding HIL as a supplementary tool, field research can be minimized.

COVID-19 Impact Analysis

With implementations in so many products and services, the HIL market cannot experience the individual impact of COVID-19 pandemic. Flight cancellations travel bans, quarantines, restaurant closures, restrictions on all indoor and outdoor events, and a significant slowdown in the supply chain, all resulted from the counteractions taken by various governments around the globe. Some other impacts of the pandemic included rising public panic, stock market volatility, a decline in business confidence, and future uncertainty. While commerce in some goods and services drastically decreased, it significantly expanded in others.

Market Growth Factors

A Rise in Automation is Propelling the Need for HIL Technological Advancements

Automobile manufacturers are incorporating technologies like autonomous driving, accident avoidance systems, and enhanced driver aid systems. ECUs, algorithms, and software used in autonomous technologies are tested using hardware-in-the-loop techniques. Hardware in the loop test bench is used to check the sensor data for cameras, radar, LiDAR, image signal processors, GPS, and other sensors. HIL simulators enable developers to verify new software and hardware automotive alternatives while adhering to quality standards and time-to-market constraints because in-vehicle driving tests to assess the performance and diagnostic features of Engine Management Systems are frequently time-consuming, expensive, and unreproducible.

Application of HIL in Multitude of Areas like Robotics, Aviation and Offshore Systems

The demand for hardware in the loop testing solutions that can fulfill these new benchmarks has increased as a result of the expanding functionality in contemporary cars. Hardware-in-the-loop solutions are primarily employed in the aviation industry for the validation and verification of aeronautical control systems. The hardware in the loop technique is used for the majority of testing demands because physical testing in this industry may be extremely dangerous for both real plants and people. Control systems and mechanical structures are typically constructed concurrently in offshore and marine engineering. Only following integration is possible to test the control systems.

Marketing Restraining Factor:

Lowering Demand of HIL Systems Due To High Complexity and Price

As building the mathematical model can be challenging depending on the variables and function blocks added to the system, hardware in the loop is a tough technique to apply. Microgrids, aviation models, and the development of automotive environments are examples of complex systems that call for hardware which can handle intensive data processing. In order to run the simulation model, companies must first invest in a costly initial configuration of real-time simulators and rack computers. A HIL simulator must be extremely complicated to run at high speeds or to use dedicated IO to produce high frequencies.

Hardware in the Loop Market Share and Industry Analysis Report 2021

Type Outlook

Based on the type, the hardware in the loop market is bifurcated into open loop, and closed loop. The closed loop segment acquired a significant revenue share in the hardware in the loop market in 2021. A closed-loop feedback loop on universal testing machines transmits data constantly from the closed-loop controller to the motor as well as from the motor to the closed-loop controller. The load rate and stress rate, for example, can remain constant throughout the testing due to this continuous input. Closed-loop systems are more accurate because they can respond quickly to potential changes.

Vertical Outlook

On the basis of vertical, the hardware in the loop market is segmented into automobile, aerospace, defense, power electronics, research & education, and others. The automobile vertical segment garnered the largest revenue share in the hardware in the loop market in 2021. The growth is notable because more and more autos are using the hardware-in-the-loop technology to create improved ECUs, shorten the time to market, and meet different industry standards. The testing of Battery Management Systems, LiDAR, computer vision, and other crucial components must evolve due to new technological advancements in electric vehicles and autonomous driving.

Hardware in the Loop Market Report Coverage
Report Attribute Details
Market size value in 2021 USD 751.1 Million
Market size forecast in 2028 USD 1.5 Billion
Base Year 2021
Historical Period 2018 to 2020
Forecast Period 2022 to 2028
Revenue Growth Rate CAGR of 10.4% from 2022 to 2028
Number of Pages 179
Number of Tables 275
Report coverage Market Trends, Revenue Estimation and Forecast, Segmentation Analysis, Regional and Country Breakdown, Competitive Landscape, Companies Strategic Developments, Company Profiling
Segments covered Type, Vertical, Region
Country scope US, Canada, Mexico, Germany, UK, France, Russia, Spain, Italy, China, Japan, India, South Korea, Singapore, Malaysia, Brazil, Argentina, UAE, Saudi Arabia, South Africa, Nigeria
Growth Drivers
  • A Rise in Automation is Propelling the Need for HIL Technological Advancements
  • Application of HIL in Multitude of Areas like Robotics, Aviation and Offshore Systems
  • Lowering Demand of HIL Systems Due To High Complexity and Price

Regional Outlook

Based on the region, the hardware in the loop market is analyzed across North America, Europe, Asia Pacific, and LAMEA. The Asia-Pacific region dominated the hardware in the loop market with the maximum revenue share in 2021. India, China, and Japan are major market influencers. Hardware sales in the loop market have increased as a result of the industries' explosive growth in the automotive, aerospace, and power electronics fields. The increased initiatives to expand manufacturing units and factories in this region would further propel the segment growth.

Free Valuable Insights: Global Hardware in the Loop Market size to reach USD 1.5 Billion by 2028
